 L-12iD Document Camera

DOCUMENT CAMERA ELMO L-12iD


Essential teaching tool , simple & stylish, the Elmo L-12iD now from EAPL, India.
Best Document camera for the Interactive classroom has evolved.
96x Zoom and 3.4M Sensor provides Superb image quality and full motion video in 60fps.

Visualiser - ELMO L-12iD Document Camera
Help maintain your Students' interest with high quality Images. Enhances Students Understanding, Saves 95% Lab Activity Time and so on..

L-12iD is an exceptionally popular Teacher’s Tool line of classroom document cameras. L-12iD is used to enlarge small images, content, or objects, which are generally invisible to the naked eyes. ELMO L-12iD is an all-inclusive document camera designed for teachers looking to incorporate 21st century classroom technology to create dynamic lessons that enhance learning, interaction, creativity and academic performance of students. 3.4M sensor incredible image quality, 8X optical Zoom enable to record lecture in classroom/conference hall with outstanding video quality and save it to the PC/Laptop via HDMI/RGB cable for future reference. ELMO L-12iD Enhanced zoom capability, multi-directional camera positions, video recording function without a computer, is easy to connect, operate and simply enables you to place any item under the camera to display them to the audience..

ELMO L-12iD Features

Superb Image Quality with HDMI in and out built in.
Remote Control allow you to contol all features of Document camera
Get Up Close and Personal: 96x zoom. 12x optical zoom and 8x digital zoom.
The most flexible document camera: Bend it, Twist it, Fold it.
RGB /HDMI IN/OUT allows for viewing and storing images and videos in incredible quality
Capture Your Lesson or take snapshots with your L-12iD to view your lessons later.
3.4M sensor provides incredible superb image quality
The ELMO Tablet partners effortlessly with an ELMO document camera for dynamic, smooth-flowing lessons.

Visualiser ELMO L-12iD Specifications

LENS F: 3.2-3.6, f= 4.0mm - 48.0mm
FRAME RATE 30 fps
PIXELS 2,144 (H) x 1,588 (V)(Total), 1,920 (H) x 1,536 (V) (Effective)
ZOOM Powered, 12x optical
RESOLUTION Analog RGB: 800 (H) x 800 (V) TV lines or more
IMAGE PICK-UP DEVICE 1/2.8" CMOS sensor 3,400,000 pixels
SHOOTING AREA 1080p: Max. 16 9/16" x 9 3/16" (420 x 233 mm) Min. 1 15/16" x 1 1/16" (48.5 x 27.5 mm)
720p: Max. 16 9/16" x 9 3/16" (420 x 233 mm) Min. 1 15/16" x 1 1/16" (48.5 x 27.5 mm)
SXGA: Max. 16 9/16" x 13 1/8" (420 x 334 mm) Min. 1 15/16" x 1 1/2" (48.5 x 38.5 mm)
WXGA: Max. 16 9/16" x 10 3/16" (420 x 259 mm) Min. 1 15/16" x 1 3/16" (48.5 x 30.5 mm)
XGA: Max. 16 9/16" x 12 5/16" (420 x 313 mm) Min. 1 15/16" x 1 7/16" (48.5 x 36.5 mm)
IMAGE MODE Text1 / Text2 / Text3 / Graphics1 / Graphics2
MOVIE STORAGE Provided
STILL IMAGE STORAGE Provided
FOCUS CONTROL Auto / Manual / Zoom Sync
DIGITAL ZOOM 8x
WHITE BALANCE Auto / One-Push / Manual
BRIGHTNESS CONTROL Auto (with level adjustment) / Manual
IMAGE SAVE SD memory card / SDHC memory card / USB flash drive
PAUSE Provided
SUPPORT FUNCTIONS Highlight, Mask, Scroll (in digital zoom), Mosaic, Split screen, PinP (Picture-in-Picture),
Color filter, Microscope, Image rotation (0º/180º), Positive/negative conversion, Color/B&W selection
ANNOTATION Provided (CRA-1 use)
LIGHTING (LED) White LED
INPUT SELECTION Main / External
MEMORY INTERFACE SD memory card slot x 1, USB host (2.0 compliant) Type A receptacle x 1
HDMI output Image output: 1080p/720p, Audio output: PCM 44.1 kHz sampling frequency
INPUT TERMINALS RGB input mini D-sub 15-pin connector, female x 1 HDMI imput terminal x1,
Mic In/Line In terminal (shared), 3.5 mm-diameter stereo mini jack x1
OUTPUT TERMINALS RGB output mini D-sub 15-pin connector, female x 1 HDMI output terminal x 1,
Line Out terminal 3.5 mm-diameter stereo mini jack x 1
ANALOG RGB OUTPUT 1080p: 1,920 x 1,080 @ 60 Hz, 720p: 1,280 x 720 @ 60 Hz SXGA: 1,280 x 1,
024 @ 60 Hz,WXGA: 1,280 x 800 @ 60 Hz, XGA: 1,024 x 768 @ 60 Hz
EXT. CONTROL TERMINAL USB device (2.0 compliant) (UVC Compliant) Mini-B receptacle x 1
DIMENSIONS (W x D x H) (355 x 373.5 x 426.5 mm) setup, (195 x 294 x 469 mm) folded
WEIGHT Approx. 7.1 lbs (3.2 kg) (main unit only)
POWER SOURCE 12V DC (AC adapter AC 100 - 240V)
POWER CONSUMPTION 16.2 W (AC adapter included)
PACKAGE CONTENT AC adapter, power cord, USB cable, Instruction manual, Image Mate CD-ROM,
Infrared wireless remote control, AAA battery, Easy start-up guide, warranty sheet
