 L-12iD Document Camera

Visualizer VZ-3neo


VZ-3neo a portable document camera delivers excellent imaging performance With the high quality lenses and high resolution image sensor.
It's high quality component deliver high performance, stability and reliability.

Visualizer VZ-3neo Document Camera
for better teaching and learning, enhances Students understanding, increases participation and knowledge retention, keeps the Students energized and so on..

Document Camera VZ-3neo is the perfect combination of high-quality components and remarkable expertise, delivers the smoothest true-to-life, high-quality images high resolution, high frame rates, fast & accurate autofocus, and zooming. VZ-3neo Visualizer system includes all the core features that every user requires. The camera, light system, and electronic hardware are all integrated into the Visualizer's arm. An optional dry-erase work surface is available for the VZ-3neo Visualizer. This allows a user to write directly on a presentation, enabling the device to be used spontaneously as a whiteboard. VZ-3neo Visualizers are highly compact and portable systems that can easily be used to serve a number of different rooms. They are available either with or without an integrated working surface. The version without working plate enables permanent mounting directly onto a desktop or podium using the supplied 'swivel plate'. The added advantage of this, is that the unit can be rotated sideways through 90 ° facilitating easy storage, and allowing the desktop surface area to remain completely obstruction-free. VZ-3neo is the best document camera. It is easy to operate, simply enables you to place any item under the camera connect it to the projector for large image display. Such Document Camera can be easily placed anywhere occupying less space with compact design.

Document Camera Features

Excellent Imaging Performance
1-CMOS native 1080p full HD camera with 30 frames per second, and sRGB color precision
Write on your Visualizer
An optional dry-erase working surface is available for writing during a presentation

Installation /Swivel Plate option
Optional 'swivel plate' this can be rotated sideways through 90° allowing the desktop surface to remain obstruction-free.
Optional Wireless Connectivity
Optional BYOD feature pack enables the VZ-3neo to be used with the vSolution Connect and vSolution Control apps

Adjustment-Free Lighting
Light system is optimized for the working surface,never need to make any light adjustments.
Easy To Use / Zoom Wheel
Multiple-speed zoom wheel, and All other controls such as focus, brightness, etc., are adjusted on top of the camera head.

Visualiser VZ-3neo Specifications

LENS Wide angle, 28mm, f4.7
ZOOM 12x zoom (6x optical, 2x digital) multiple-speed zoom wheel
FRAME RATE 30 frames (in all resolutions)
Resolution 980 lines
EFFECTIVE PIXELS 1920 x 1080
IMAGE PICK-UP DEVICE 1-CMOS 1/3"
SHOOTING AREA 290mm * 400mm (Hight:200mm)
FOCUS Range 15mm - 260mm
FOCUS CONTROL Auto/Manual
WHITE BALANCE Auto/Manual
BRIGHTNESS Auto/Manual
IMAGE DISPLAY Negative image / negative-blue image / black and white image
LIGHTING high-brightness LED light
BOTTOM LIGHT With optional lightbox
CONNECTORS 1x HDMI in, 1x HDMI out, IP addressable LAN port,
mini USB 2.0 device port, USB 2.0 host port,
HDMI OUTPUT HDMI (DVI output via optional HDMI-DVI adapter cable)
RS232 PORT (if required external LAN to RS232 adapters can be used)
ETHERNET / LAN PORT Yes, with PoE+
OPERATING TEMPERATURE 0°-40°C (32°-104°F) / 40-60%
SWIVEL PLATE Yes, with 90° rotation
DRY-ERASE WORKING SURFACE Optional
DIMENSIONS (W x D x H) 488mm x 305mm x 525mm (when setup)
574mm x 305mm x 135mm (when folded)
WEIGHT 3.76kg (8.3lbs)
POWER SOURCE External desktop power pack 12V: multi range 100-240V, 24W
Power over Ethernet Plus (IEEE 802.3at-2009 standard)
ANTI-THEFT DEVICE T-Lock (Kensington® Lock), and table lock bolt
WARRANTY 5 Years
PACKAGE CONTENT Cable shield, power supply 1.8m, LAN cable 1.8m, mini USB cable 1.8m, HDMI cable 1.5m

Do you want to see live demo of Visualiser VZ-3neo?
